Analysis on the Problem of Tooth Jumping in Pipe Cutting of Pipe Cutting Machine

Update:25 Sep 2020

  The pipe cutting machine was disassembled and analyze […]

  The pipe cutting machine was disassembled and analyzed, and the whole machine was not damaged except for abnormal wear. After the re-assembly was completed, the pump station was used to mobilize the work and carried out no-load operation. No extraordinary signs were found.
In the subsequent pipeline cutting load commissioning stage, following the cutting depth and the operation of the groove, the vibration amplitude of the chain and sprocket of the self-climbing hydraulic pipe cutting machine increased, and the tail wheel and even the sign of job-hopping appeared, accompanied by chains and chains. Wheels differ in level of wear.
  Because of the impact of the tail wheel beating, the chain feed is unbalanced, and the self-climbing hydraulic pipe cutter snakes, and the pipe cutter's milling blade is damaged, and the beveling cutter hits the teeth. After analyzing the technical staff, the emergence of this type of situation is mainly composed of the following aspects:
 1. I feel that the tail wheel tension of the self-climbing hydraulic pipe cutting machine is lacking. The promotion of the tension of the tail wheel is related to the tension of the chain. The deformation of the fastening bolt on the right of the front end is the reason for the lack of the tension of the right tail wheel. Also because of the vibration of the tail wheel sprocket jumping teeth, the assembly of the fastening bolts at the front end also forms a momentary blow, and the load also increases in response, so that the connecting rod is deformed, the fastening bolts take effect, and the screw deforms and twists.
 2. The alignment of the pipe cutter and the head wheel is considered a problem. After replacing the tail wheel, the craftsman rechecked the levelness of the nose wheel shaft, and it reached the standard requirement of 0.2mm/m.
 3. Check the pitch error of the head, tail gear and chain of the self-climbing hydraulic pipe cutting machine. XJ-QG-1 self-climbing hydraulic pipe cutting machine's tail wheel sprocket has 16 teeth, the measured sprocket tooth index circle diameter and the calculation formula based on the index circle diameter d=p/sin (180/z) , The pitch p of the tail wheel sprocket teeth is also regulated. The standard theoretical size of the sprocket is measured abnormally, and the deviation is only 0.15mm. Therefore, the chain pitch was measured again. Measure data within the length of 600 sisters, and measure 10 points per piece. The pitch data of the orbiting chain measured are all abnormal, but the wear situation is relatively tight.
   4. Using the video material invention sent by the customer again, the self-climbing hydraulic pipe cutting machine must be supplemented by sand and gravel when cutting the fuel conveying pipeline, which caused the accumulation of sand and chip data and the mixing of oil, which made the pipe cutting machine The chain and sprocket on the right are full of adhesion, and the chip adhesion is more tense especially when cutting the bottom pipe. The chain and sprocket on the left have no effect. As a result, the sprocket on the right will increase the track on the right due to the influence of these chips. The particles of these materials are very small, and the materials deposited on the chain and sprocket are extremely dense. The more deposited, the greater the crawling resistance. This is often the primary reason for the tail wheel sprocket to jump teeth. This type of chip accumulation test was also carried out in the factory, and the simulation test also proved this distinction.
